Rotary Milking Parlors
BECO PRODUCTS
BXR Rotary 32-130 Stalls
The BECO BXR rotary is designed and engineered to withstand the rigors of a 24 hour dairy operation. The platform’s heavy duty construction and design maximizes milk quality and operator efficiency. From the CIP swivel to the raised deck, heavy duty construction, and properly aligned stalls, the BXR rotary was built with extreme detail given to strength, milk quality, and efficiency.
HOVER FOR MORE IMAGES
Heavy Duty Construction with Heavy Duty Cabinets
- Heavy duty centering devices
- Does not rely on spokes or swivel to stay centered
- Substantial swivel support
- There is no weight resting on the swivel
- Robust stainless steel cabinets
- Designed for the rigors of a 24 hour dairy operation
Dual Pinch Style Electric Planetary Drives
- Pinched drives
- Equal pressure placed on both sides of beam
- Electric planetary drives
- Designed to go forward, reverse, and to be used as a brake
Wheels and Tracks
- Flat wheels and flat track
- Allows for superior surface area
- Reduces friction
- 2 wheels per stall for added strength
Raised Deck
- Allows for proper 2% slope of milk lines
- Eliminates any lifting of milk
Extended Deck
- Keeps the basement clean and dry
HOVER FOR MORE IMAGES
Smart and Simple Control System
Operator Control Panel
- Customizable with 3 speed options
- Forward/reverse and start/stop
- Emergency stop
Smart PLC Control System
- If the platform stops for any reason, simply look at the lights to see why
Drives
- Controlled by variable speed drives
- Includes RF filters on input and output of drives
CIP Swivel
- Allows platform to rotate while washing is taking place
- Milk special needs cows, and after they are milked you can start the wash cycle
- When special needs are complete and still in wash cycle, rotate the platform to get the cows off
- Operators can stay in one place washing units as the platform turns and wash is taking place
- No need to park the platform in a specific place and hook up CIP hoses
- Only platform on the market to offer a CIP swivel
Properly Aligned Stalls and Platform Rotation
- Stalls aligned properly with platform rotation
- Takeoff unit comes first and then the cow
- Angled stalls allow cows leg to be moved forward of the takeoff chain
- Allows for smoother unit retract
BECO does all this with an industry leading 5 year warranty on its equipment.
